Electrical Machinery Rotor Ring Welding Equipment
1. Applications:
Large-scale and middle-scale electrical machinery rotor ring copper brazing, Pole coil joint, feeler of electrical equipment, shield Cutters and plane hard brazing of other work piece. The device is adopted to marine, mining, Railway traction motor, tunnelling works and coal mine machinery etc.
2. Main performance:
(1)Transistor induction heating power source is adopted, with high efficiency and good welding quality;
(2)The welding is adapted to the integrated brazing and sequence welding.
(3)It can meet the requirements for heating of silver-base and copper base alloy brazing material and both the welding strength and the conductivity can meet the technological requirements.
(4)Global leading welding procedure is adopted to solve many problems regarding the welding for the users.
3. Composition of device
The device is made up of middle frequency power, middle frequency transformer, infrared ray thermometer, and induction heater, water chilling unit and welding auxiliary machine.
4. Main technical parameters
Model | Rated power (KW) | Rated frequency (KHZ)
| Max. Diameter (mm)
| Max. Height ( mm )
| Frequency of making ( min )
| Heating temperature ( ℃ )
| water flow (T/h) |
MFMB-100 | 100 | 5-15 | 350 | 10-40 | ≤4 | 850 | 1.5-2 |
MFMB-160 | 160 | 6-10 | 550 | 10-80 | ≤4 | 850 | 1.7-2.3 |
MFMB-250 | 250 | 6-10 | 750 | 10-100 | ≤6 | 850 | 3-5 |
MFMB-300 | 300 | 4-10 | 900 | 10-100 | ≤8 | 850 | 4-6 |
MFMB-400 | 400 | 3-10 | 1050 | 10-120 | ≤12 | 850 | 5-7 |
MFMB-500 | 500 | 3-10 | 1200 | 10-150 | ≤12 | 850 | 8-10 |
MFMB-600 | 600 | 3-10 | 1500 | 10-200 | ≤12 | 850 | 10-12 |
Customized designs are available.
